Low Pressure Misting System with Monoblock Pump

This low-pressure misting system using a 150 PSI diaphragm monoblock pump is designed for versatile cooling and dust control applications. Ideal for terrace gardens, outdoor areas like porticos, and indoor spaces requiring gentle misting, it delivers efficient performance when properly installed.

Setup Instructions

Positioning the Pump:

Positioning the Pump

Always place the pump below the water tank level to ensure effective suction and maintain optimal pressure throughout the system.

Suitable Applications

  • Dust suppression in industrial or construction areas.
  • Cooling for patios, balconies, or terrace gardens.
  • Light misting for indoor green spaces or semi-covered areas.
Suitable Applications
Water Quality

Water Quality

Use clean water only. Avoid liquids with sediments or debris, as they can clog the nozzles and impair mist output.

Pressure Adjustment

Regulate pressure by partially opening the liquid return line. Always allow a portion of water to circulate back into the tank to prevent overheating and preserve pump life

Pressure Adjustment:
Return Line Caution

Return Line Caution

Do not fully close the return line. Doing so will strain the pump and degrade system efficiency due to overheating.

Connection & Sealing Tips

Use Teflon tape at all joints and threaded areas to avoid leaks and maintain pressure integrity.

Connection & Sealing Tips:
Recommended Installation Practice

Recommended Installation Practice

It is advisable to hire a certified plumber or technician for the initial installation to avoid incorrect assembly.

Components & Installation

Included Accessories

9

16 meters of high-quality PU hose

9

Precision misting nozzles for efficient spray dispersion.

Nozzle Placement

9

Install nozzles at a 45-degree angle from the sides of the target area for maximum coverage and cooling efficiency

Mounting Tips

9

Secure hoses and nozzles using plastic tags or cable ties to poles or frames for stability and ease of maintenance

Technical Specifications

Pump Type System Type
150 PSI Diaphragm Monoblock Low Pressure Misting

Maintenance Guidelines

Water Softeners for Hair and Skin

Routine Cleaning

Periodically remove and clean nozzles to prevent mineral buildup

Electric Water Softeners

System Check

Inspect all joints, hoses, and return lines monthly for wear or leaks.

Commercial Water Softener Systems

Seasonal Shutdown

If unused for long periods, flush the system with clean water and dry all components.
