UV Filter Housings
A UV filter housing is a specialized enclosure designed to protect and support the UV lamp and quartz sleeve used in ultraviolet water purification systems.
- Manufactured in Ambattur, Chennai
- Sized to your site and water
- Installation and service support
Key Features
High-Grade Stainless Steel
Most housings are made from polished SS304 or SS316 for durability, corrosion resistance, and reflective efficiency.
Sealed, Pressure-Rated Chambers
Keeps UV components dry while allowing water to flow through efficiently.
Lamp and Sleeve Support
Secures quartz sleeves and UV lamps to prevent breakage or misalignment.
End Caps and Gaskets
Create watertight seals and enable safe, tool-free maintenance.
Multiple Sizes
Available in flow capacities ranging from 1 GPM (residential) to 100+ GPM (commercial/industrial).
Why Use a UV Filter Housing?
Maximize UV Exposure
Internal reflectivity increases UV lamp efficiency.
Protect Vital Components
Shields fragile lamps and sleeves from impact and contamination.
Maintain Sanitation
Prevents microbial growth and supports clean-in-place protocols.
Adaptable System Design
Compatible with residential, commercial, and municipal systems.
Applications
Residential Water Disinfection
Whole-house UV treatment for well or city water.
Laboratory and Pharmaceutical
Sterile water supply systems.
Food & Beverage Processing
Protects product quality in bottling and ingredient water.
Industrial and Municipal
Large-scale systems for drinking water, wastewater reuse, or cooling towers.
Choosing the Right UV Filter Housing
| Factor | Recommendation |
|---|---|
| Material | Use SS316 for corrosive or food-grade applications; SS304 for standard systems |
| Flow Rate | Match housing size to system GPM and UV lamp specs |
| Port Size | Choose inlet/outlet sizes that fit your plumbing (¾”, 1”, 1.5”) |
| Certifications | NSF/ANSI 55, CE, or UL listings for regulated environments |
| Maintenance Access | Look for tool-free designs or swing caps for fast lamp changes |
Maintenance Tips
Clean quartz sleeves every 6–12 months to remove mineral buildup.
Replace UV lamps annually, even if they still light up—they lose germicidal strength over time.
Check seals and O-rings regularly for wear or degradation.
Flush the system after maintenance to remove air pockets and ensure full lamp exposure.
Choose with confidence
Choosing the right filter housings and spares
- Confirm the flow rate and working pressure of the line.
- Pick the cartridge length and diameter (10", 20", jumbo) the system uses.
- Choose PP housings for general water and SS for hot, high-pressure or hygienic duty.
- Check inlet and outlet thread sizes before ordering.
- Keep a set of spare cartridges and O-rings on site.
Shop
Filter Housings & Spares you can order online
Prices and stock shown in the shop. For bulk orders or help choosing, ask us.
How we work
From first message to running system
- 01
Tell us the need
Share your requirement, site details and any water report or photos.
- 02
We review and size
We ask the right questions and size the system for your site.
- 03
Clear quotation
You get a quote with scope, specification and timelines.
- 04
Build, install, support
We manufacture, install, commission and stay available for service.
Related solutions
More in Filter Housings & Spares
Questions, answered
FAQs about UV Filter Housings
Still unsure? Ask us directly or call +91 95000 55565.
What is a UV filter housing used for?
A UV filter housing is used to enclose and protect the UV lamp and quartz sleeve in a water disinfection system. It ensures that water flows around the UV lamp properly while keeping electrical components dry and secure.
Are UV housings made from stainless steel or plastic?
Most UV filter housings are made from stainless steel (SS304 or SS316) for durability, hygiene, and optimal UV reflection. Plastic models exist but are typically used in low-flow, residential setups.
Can I replace the UV lamp without removing the housing?
Yes, many UV housings are designed with tool-free end caps or service ports that allow for easy lamp and quartz sleeve replacement without disconnecting plumbing.
How often should I clean the quartz sleeve in my UV housing?
Quartz sleeves should be cleaned every 6 to 12 months, or more frequently if you have hard water. Mineral deposits on the sleeve can reduce UV effectiveness.
Do UV filter housings come in different sizes?
Yes, UV housings vary in size based on the system’s flow rate—from 1 GPM units for under-sink systems to 100+ GPM for commercial or municipal setups.
What’s the difference between SS304 and SS316 UV housings?
SS304 is standard-grade stainless steel for most installations. SS316 offers superior corrosion resistance and is recommended for saltwater, aggressive chemicals, or food-grade use.
How long does a UV lamp last inside the housing?
UV lamps should be replaced every 9,000 to 12,000 hours (approximately once a year), as their germicidal intensity weakens over time, even if the lamp is still glowing.
Can I install a UV filter housing horizontally?
Most UV housings are designed for vertical installation to ensure even exposure and avoid air bubble interference. Always follow the manufacturer’s guidelines.
Are UV housings compatible with any brand of lamp or ballast?
Not always. Some UV housings are proprietary. Always check lamp size, wattage, and pin configuration to ensure compatibility with your housing and ballast.
What micron rating should I use?
For RO pre-filtration 5 micron is common; sediment pre-filters often use 20 to 50 micron. The right rating depends on your water and the equipment you protect.
